The PULSE-80 has been designed to meet the highest requirement in term of electro-magnetic compatibility. As such, the power supply and all digital I/O have been carefully designed. All electrical specification are given in the following tables.

Power Supply

temConditionsMin.Typ.MaxUnit

Input Voltage Range

-

3.15

55.25

V

Typical Power Consumption

--

1.1

1.25

W

Inrush Current Consumption

-

-

-

675

mA

I/O Interfaces

ItemConditionsMin.Typ.MaxUnit

LVTTL Inputs

Low Level Input Voltage

-

0

0.8

-

V

High Level Input Voltage

-

-

2

3.3

V

LVTTL Outputs
Low Level Output VoltageIL=100μA00.4-V
IL=16mA00.4-
High Level Output VoltageIL=100μA-2.43.3V
IL=16mA-2.43.3

ESD Caution

Charged devices and circuit boards can discharge without detection. Although this product integrates a certain protection level, circuitry damages may occur in contact to hight energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.

Pulse-80 OEM has been qualified to the following ESD norms :

ESD normDescription
JESD22-A114

Electrostatic discharge voltage (human body model) - By design : Class 2 - 2 kV

JESD22-A115Electrostatic discharge voltage (machine model)- By design : Class A - < 200 V

Electrical Absolute Maximum Rating

Important note

Stresses above those listed under the Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only; functional operation of the device at these or any other conditions above those indicated in the operational section of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

Item

Rating

Unit

VCC to Ground

0 to +.5.25

V

Input (LVTTL) to Ground

- 0.5 to + 4.6

V

Output (LVTTL) to Ground- 0.5 to + 4.6V
